16 1290 Infinity Quaternary Pump User Manual
1 Introduction
Positions of the Multi Purpose Valve
Normal Operating Mode With Jet Weaver and Optional Inline Filter
In this mode, the flow passes an optional Jet Weaver and the optional inline
filter. This configuration is recommended for special applications which
require an increased mixing efficiency.
Figure 4 Valve position in normal operating mode with Jet Weaver
)URPSXPS
7RV\VWHP
,QOLQHILOWHU
-HW:HDYHU
