© Agilent Technologies 2001–2003 Agilent 3070 System Installation Manual (MS Windows Version) 2-54
Chapter 2: MS Windows System Installation Reference: Controller Cables and Devices
Table 2-20 X2100 controller cables and devices — Series 3
Cables Part No Description
A E4000-61628 Control Cable
B 8120-6713 Footswitch Extension Cable, RJ-11
C 8120-8728 LAN Cable, 1-meter, RJ-45 to RJ-45
D 10833C 4-meter GPIB Cable
E 10833A 1-meter GPIB Cable
F Optional ASSET Boundary-scan PCI-400 Controller Card, cable and BSI Card
G 03066-61629 Strip Printer Cable, RS-232, DB9(f) to DB25(m) cross-conn., 3-m
H 03066-61640 Video Extension Cable (1 for 327X, 2 for 307X / 317X)
K 8120-6794 Keyboard / Mouse Extension Cable
L 8120-3543 2-meter LAN Cable, BNC to BNC
M E4000-61630 LAN Cable, BNC to SMB for ControlXT/XTP Cards
N E4000-61629 LAN Cable, SMB to SMB for ControlXT/XTP Cards
