Chapter 2: MS Windows System Installation Reference: Testhead Cards
Testhead Cards Table 2-15 shows available testhead cards with their
diagnostics names, cards <keywords> statements,
pattern applications rates and part numbers.
If Changing a ControlXT/XTP or System Card
See Private LAN and Serial Port MUX on page 2-59.
Table 2-15 MS Windows supported cards with DGN names, cards <keywords> statements, pattern application rates and
part numbers
Card Type DGN
Config
Name
cards <keywords> Statement in the System
Config File
Pattern
Application
Rate (MP/s)
Card P/N
Access Access
access
6,12,20 E1061-66501
Analog Analog
analog
6,12,20 E1121-66526
Ana_DD
analog double density
2,6,12,20 E4000-66542
Ana_DD2
analog double density
2,6,12,20 E4000-66551
ASRU ASRU_C
asru c revision
2,6,12,20 03066-66532
Control Ctl_Xt
control xt
2,6,12,20 E4000-66512
Ctl_Xtp
control xtp
2,6,12,20 E9900-66504
Hybrid H_PpuStd
hybrid standard
6 E4045-66527
H_StdDD
hybrid standard double density
6 E4000-66540
H_StdDD2
hybrid standard double density
6 E4000-66550
H_PpuDD
hybrid standard double density
6 E4000-66546
HPpuDD2
hybrid standard double density
6 E4000-66550
H_AdvDD
hybrid advanced double density
12 E4000-66544
HAdvDD2
hybrid advanced double density
12 E4000-66550
