© Agilent Technologies 2001–2003 Agilent 3070 System Installation Manual (MS Windows Version) 2-45
Chapter 2: MS Windows System Installation Reference: DUT Power Supplies
DUT Power
Supplies
This section contains:
■ Voltage Ranges, 2-45
■ Module Mappings, 2-45
■ DUT Power Supplies Allowed, 2-45
■ GPIB Addresses and Device Files, 2-46
Voltage Ranges
DUT power supplies are set at the factory in one of two
configurations:
• Option 220 for line voltages of 200–220 volts.
• Option 240 for line voltages of 230–240 volts.
DUT Power Supplies Allowed
Table 2-16 lists the DUT the power supplies allowed.
Module Mappings
Table 2-17 on page 2-46 lists the default DUT power
supply mappings for each module.
The commented ("!") statements illustrate that a power
supply number (1 through 24) cannot be assigned more
than once in a testhead, and a channel number (1
through 6) cannot be assigned more than once in a
module.
For 307X systems with a support bay, if it is necessary
to determine which DUT power supply is wired to
which module, the DUT/ASRU cables E4000-61602 are
labeled on both ends with the module numbers to which
they are routed.
Agilent 317X systems use cable numbers E4000-61606
and E1170-61607.
Table 2-16 DUT power supplies allowed
Product No. Model No. Description
44940A 6624A 4 outputs: 2 @ 0-7 V, 0-5 A or 0-20 V, 0-2 A and 2 @ 0-20 V, 0-2 A or 0-50 V,
0-0.8 A
44941A 6621A 2 outputs: 0-7 V, 0-10 A and 0-20 V, 0-4 A
E4034A 6634A 1 output: 1-100 V, 0-1 A
E3784A 6642A 1 output: 0-20 V, 0-10 A
