© Agilent Technologies 2001–2003 Agilent 3070 System Installation Manual (MS Windows Version) 2-42
Chapter 2: MS Windows System Installation Reference: Rotating the Testhead
Rotating the
Testhead
CAUTION
✸
Remove all objects, including the monitor /
keyboard support arms, from the rotational path of
the testhead.
If the testhead would hit anything, damage could
result.
CAUTION
✸
Remove the shipping bolts before attempting to
rotate the testhead. Otherwise, damage can result.
1 Open the pod door.
2 Press and hold the testhead rotation switch inside the
pod until the testhead rotates to the desired position.
There is also sometimes a testhead rotation switch on
the rear of the pod.
NOTE
The PDU must be turned on for the testhead
rotation switch to be active.
