Chapter 2: MS Windows System Installation Reference: DUT Power Supplies

GPIB Addresses and Device Files

If the DUT power supplies are functional, a supply’s

GPIB address can be determined by tracing the cabling

to determine which supply is connected to the module.

If the supply has a front panel and is accessible, the

GPIB address can be read from the front panel of the

supply.

Table 2-18 lists DUT power supply GPIB addresses and

device files. See If a DUT Power Supply is Replaced

on page 2-40 for more information about DUT power

supply GPIB addresses.

Table 2-17 Default DUT power supply mappings for each module (rear view of testhead)

Module 0 Module 2

supplies hp6624 13 to 16 asru channels 1 to 4 ! supplies hp6624 5 to 8 asru channels 1 to 4

! supplies hp6621 13 to 14 asru channels 1 to 4 supplies hp6621 5 to 6 asru channels 1 to 4

! supplies hp6624 23 to 24 asru channels 5 to 6 ! supplies hp6624 19 to 20 asru channels 5 to 6

supplies hp6621 23 asru channels 5 to 6 ! supplies hp6621 19 asru channels 5 to 6

! supplies hp6634 23 asru channels 5 supplies hp6634 19 asru channels 5

! supplies hp6634 24 asru channels 6 supplies hp6634 20 asru channels 6

! supplies hp6642 23 asru channels 5 to 6 ! supplies hp6642 19 asru channels 5 to 6

Module 1 Module 3

supplies hp6624 9 to 12 asru channels 1 to 4 supplies hp6624 1 to 4 asru channels 1 to 4

! supplies hp6621 9 to 10 asru channels 1 to 4 ! supplies hp6621 1 to 2 asru channels 1 to 4

! supplies hp6624 21 to 22 asru channels 5 to 6 supplies hp6624 17 to 18 asru channels 5 to 6

! supplies hp6621 21 asru channels 5 to 6 ! supplies hp6621 17 asru channels 5 to 6

supplies hp6634 21 asru channels 5 ! supplies hp6634 17 asru channels 5

supplies hp6634 22 asru channels 6 ! supplies hp6634 18 asru channels 6

! supplies hp6642 21 asru channels 5 to 6 ! supplies hp6642 17 asru channels 5 to 6

Agilent Technologies 3070 User Manual
