Chapter 2: MS Windows System Installation Reference: DUT Power Supplies
NOTE
The customer has the flexibility to modify the
DUT power supply GPIB addressing.
Table 2-18 DUT power supply GPIB addresses and device files
Power Supply Connection GPIB Address Device File
Module 0, asru channels 1-4 22
$AGILENT3070_ROOT/dev/ps0
Module 1, asru channels 1-4 23
$AGILENT3070_ROOT/dev/ps1
Module 2, asru channels 1-4 24
$AGILENT3070_ROOT/dev/ps2
Module 3, asru channels 1-4 25
$AGILENT3070_ROOT/dev/ps3
Module 0, asru channel 5 or 5-6 26
$AGILENT3070_ROOT/dev/ps4
Module 0, asru channel 6 27
$AGILENT3070_ROOT/dev/ps5
Module 1, asru channel 5 or 5-6 28
$AGILENT3070_ROOT/dev/ps6
Module 1, asru channel 6 29
$AGILENT3070_ROOT/dev/ps7
Module 2, asru channel 5 or 5-6 1
$AGILENT3070_ROOT/dev/ps8
Module 2, asru channel 6 2
$AGILENT3070_ROOT/dev/ps9
Module 3, asru channel 5 or 5-6 3
$AGILENT3070_ROOT/dev/ps10
Module 3, asru channel 6 4
$AGILENT3070_ROOT/dev/ps11
