© Agilent Technologies 2001–2003 Agilent 3070 System Installation Manual (MS Windows Version) 1-21
Chapter 1: MS Windows System Installation Procedure: Powering the PDU and Controller
Powering the PDU
and Controller
This section contains:
■ Supply Power to the PDU, 1-21
■ Switch on the Controller, 1-21
■ Configuring the System to a Network, 1-22
■ Logon as service3070 to Complete the Installation,
1-22
Supply Power to the PDU
CAUTION
✸
Disconnect testhead power before connecting or
disconnected testhead cables. Otherwise, damage
can result.
1 Connect the PDU power cable to the power source:
Instructions for connecting power are given in the
Agilent 3070 / 79000 Family Site Preparation
Manual 03066-90114, which is shipped in print with
the system.
NOTE
The PDU is not serviceable; if it is defective, it
must be replaced.
WARNING
✸
DO NOT open the PDU for any reason.
Voltages capable of causing injury or death are
present inside the PDU, even with the switches
off.
2 Switch on the Mains Disconnect Switch:
The PDU has two switches, both of which are
accessible from the rear of the pod:
■ One is the green Switched Circuits Enabled rocker
switch that enables power to the testhead – DO
NOT switch this one on yet.
■ The other is the large, red rotary Mains Disconnect
Switch that enables power to the PDU outlets,
video monitor, and system controller – switch
only this one on now.
Switch on the Controller
1 Switch on the video monitor.
2 Open the pod door and switch on the controller.
NOTE
A line of random characters may be printed on the
strip printer. This is normal and should be ignored.
