Chapter 1: MS Windows System Installation Procedure: Setting Up the KVM and Support Arms
7 Connect the KVM cables:
NOTE
The USB connectors on (the left side of) the video monitor are not used.
a Remove the cover from the rear of the video monitor, then connect the
power and signal cables.
b Replace the rear cover.
c Connect the keyboard and mouse cables.
8 Install the barcode scanner
cables:
NOTE
Perform this task only if
installing an optional
barcode scanner.
Otherwise, continue
with Task 9.
a Insert the bar code scanner cable between the keyboard cable and the
keyboard extension cable.
b Route the bar code scanner cables through the support arm cable troughs.
9 Tidy and secure all cables. Use new cable ties where necessary.
10 Replace pod cover and
door.
Re-install the pod door and use a T20 Torx driver to replace the pod cover
screws.
Table 1-2 Install the KVM and support arms (continued)
