© Agilent Technologies 2001–2003 Agilent 3070 System Installation Manual (MS Windows Version) 1-16
Chapter 1: MS Windows System Installation Procedure: Setting Up the KVM and Support Arms
Figure 1-5 Adjust the support arms
Video Monitor
Arm Vertical Tension
Adjustments (Top View)
(1/4-inch hex)
Keyboard Mouse
Keyboard Tray
Tilt Adjustment
(knob)
Pod
Arm Horizontal
Adjustments
(3/32-inch hex)
