Agilent Technologies 3070

© Agilent Technologies 2001–2003 Agilent 3070 System Installation Manual (MS Windows Version) 1-28
Chapter 1: MS Windows System Installation Procedure: Setting-Up Other Hardware
Figure 1-10 Pay-Per-Use button adapter hardware in the pod
PPU Button
Adapter
0960-2134
Dual Button
Holder with
cable
1252-8421
Right Pod, cover removed
Pod door open
To Com1 port
of controller
