Agilent Technologies PNA Series User Manual

Service Guide E8361-90001 4-47
PNA Series Microwave Network Analyzers Troubleshooting
E8361A Measurement System Troubleshooting
Table 4-8 LO Path Frequencies
Band
Network Analyzer
Frequency Band
of Problem (GHz)
Network Analyzer
Source Frequency
Setting (GHz)
Expected A17
Output
Frequency
(GHz)
Expected A18
Output
Frequency
(GHz)
0
0.010 to 0.045
.025 0.025 0.025
1
0.045 to 0.748
0.50 0.500 0.500
2
0.748 to 1.500
1.00 1.00 1.00
3
1.50 to 3.00
2.20 2.20 2.20
4
3.00 to 4.00
3.40 3.40 3.40
5
4.00 to 4.50
4.20 4.20 4.20
6
4.50 to 5.00
4.60 4.60 4.60
7
5.00 to 6.00
5.40 5.40 5.40
8
6.00 to 7.70
6.90 6.90 6.90
9
7.70 to 10.00
8.90 8.90 8.90
10
10.00 to 12.00
11.00 11.00 11.00
11
12.00 to 12.80
12.40 6.20 12.40
12
12.80 to 15.40
14.10 7.05 14.10
13
15.40 to 16.00
15.70 7.85 15.70
14
16.00 to 20.00
18.00 9.00 18.00
15
20.00 to 24.00
22.00 11.00 22.00
16
24.00 to 25.60
24.80 8.27 8.27
17
25.60 to 30.00
27.80 9.27 9.27
18
30.00 to 32.00
31.00 10.33 10.33
19
32.00 to 36.00
34.00 11.33 11.33
20
36.00 to 40.00
38.00 6.33 12.67
21
40.00 to 44.70
42.40 7.07 14.13
22
44.70 to 46.20
45.50 7.58 15.17
23
46.20 to 51.20
48.70 8.12 16.23
24
51.20 to 60.00
55.60 9.27 18.53
25
60.00 to 64.00
62.00 10.33 20.67
26
64.00 to 70.00
1
65.50 10.92 21.83
1. Performance from 67 to 70 GHz is typical and not warranted by Agilent.
