Agilent Technologies PNA Series User Manual

5-8 Service Guide E8361-90001
Theory of Operation PNA Series Microwave Network Analyzers
Source Group Operation E8361A
A8 Fractional-N Synthesizer Board
The A8 fractional-N synthesizer board uses the 5 MHz reference signal from the A10
frequency reference board to tune two VCO circuits: one that sweeps from 1500 to
3010 MHz and one that is set to a CW frequency of 2250 MHz.
In bands 0–1, these signals are mixed to produce the output frequencies listed in Table 5-2.
Table 5-2 Subsweep Frequencies
Band L.O. Harmonic Number (N)
A8 Frac-N
Synthesizer
Frequency
(GHz)
A17
LOMA 12
Frequency
(GHz)
A20 LODA
(L.O.)
Frequency
(GHz)
A12
Source 20
Frequency
(GHz)
A21
SOMA 50
Frequency
(GHz)
A23/A24
SOMA 70
Frequency
(GHz)
01
0.011 to 0.046 0.011 to 0.046 0.011 to 0.046 0.010 to 0.045 0.010 to 0.045 0.010 to 0.045
11
0.053 to 0.756 0.053 to 0.756 0.053 to 0.756 0.045 to 0.748 0.045 to 0.748 0.045 to 0.748
21
0.756 to 1.508 0.756 to 1.508 0.756 to 1.508 0.748 to 1.500 0.748 to 1.500 0.748 to 1.500
31
1.50 to 3.00 1.50 to 3.00 1.50 to 3.00 1.50 to 3.00 1.50 to 3.00 1.50 to 3.00
41
1.50 to 2.00 3.00 to 4.00 3.00 to 4.00 3.00 to 4.00 3.00 to 4.00 3.00 to 4.00
51
2.00 to 2.25 4.00 to 4.50 4.00 to 4.50 4.00 to 4.50 4.00 to 4.50 4.00 to 4.50
61
2.25 to 2.50 4.50 to 5.00 4.50 to 5.00 4.50 to 5.00 4.50 to 5.00 4.50 to 5.00
71
2.50 to 3.00 5.00 to 6.00 5.00 to 6.00 5.00 to 6.00 5.00 to 6.00 5.00 to 6.00
81
1.50 to 1.93 6.00 to 7.70 6.00 to 7.70 6.00 to 7.70 6.00 to 7.70 6.00 to 7.70
91
1.93 to 2.50 7.70 to 10.00 7.70 to 10.00 7.70 to 10.00 7.70 to 10.00 7.70 to 10.00
10 1
2.50 to 3.00 10.00 to 12.00 10.00 to 12.00 10.00 to 12.00 10.00 to 12.00 10.00 to 12.00
11 1
1.50 to 1.60 6.00 to 6.40 12.00 to 12.80 12.00 to 12.80 12.00 to 12.80 12.00 to 12.80
12 1
1.60 to 1.93 6.40 to 7.70 12.80 to 15.40 12.80 to 15.40 12.80 to 15.40 12.80 to 15.40
13 1
1.93 to 2.00 7.70 to 8.00 15.40 to 16.00 15.40 to 16.00 15.40 to 16.00 15.40 to 16.00
14 1
2.00 to 2.50 8.00 to 10.00 16.00 to 20.00 16.00 to 20.00 16.00 to 20.00 16.00 to 20.00
15 1
2.50 to 3.00 10.00 to 12.00 20.00 to 24.00 10.00 to 12.00 20.00 to 24.00 20.00 to 24.00
16 3
2.00 to 2.13 8.00 to 8.53 8.00 to 8.53 12.00 to 12.80 24.00 to 25.60 24.00 to 25.60
17 3
2.13 to 2.50 8.53 to 10.00 8.53 to 10.00 12.80 to 15.00 25.60 to 30.00 25.60 to 30.00
18 3
2.50 to 2.67 10.00 to 10.67 10.00 to 10.67 15.00 to 16.00 30.00 to 32.00 30.00 to 32.00
19 3
2.67 to 3.00 10.67 to 12.00 10.67 to 12.00 16.00 to 18.00 32.00 to 36.00 32.00 to 36.00
20 3
1.50 to 1.67 6.00 to 6.67 12.00 to 13.33 18.00 to 20.00 36.00 to 40.00 36.00 to 40.00
21 3
1.67 to 1.86 6.67 to 7.45 13.33 to 14.90 10.00 to 11.18 40.00 to 44.70 40.00 to 44.70
22 3
1.86 to 1.93 7.45 to 7.70 14.90 to 15.40 11.18 to 11.55 22.35 to 23.10 44.70 to 46.20
23 3
1.93 to 2.13 7.70 to 8.53 15.40 to 17.07 11.55 to 12.80 23.10 to 25.60 46.20 to 51.20
24 3
2.13 to 2.50 8.53 to 10.00 17.07 to 20.00 12.80 to 15.00 25.60 to 30.00 51.20 to 60.00
25 3
2.50 to 2.67 10.00 to 10.67 20.00 to 21.33 15.00 to 16.00 30.00 to 32.00 60.00 to 64.00
26 3
2.67 to 2.92 10.67 to 11.67 21.33 to 23.33 16.00 to 17.50 32.00 to 35.00
64.00 to 70.00
a
a. The analyzer presets to 67 GHz. Frequencies above 67 GHz must be entered directly.
