6-20 Service Guide E8361-90001
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8361A
Bottom Assemblies, No Options
Reference
Designator
Part
Number
a
a. Part numbers in italic typeface are for rebuilt exchange assemblies. Refer to “Rebuilt-Exchange
Assemblies” on page 6-5.
Qty Description
A16 E8364-60138 1 Test set motherboard
A17
5087-7247
5087-6247
1 LOMA 12
A18
5087-7248
5087-6248
1 MA 24
A19 5087-7139 1 Splitter
A20
5087-7129
5087-6129
1LODA
A21
5087-7130
5087-6130
1 SOMA 50
A22
5087-7238
5087-6238
1Switch
A23
A24
5087-7249 2
SOMA 70
A25
A26
5087-7225 2
Test port 1 coupler
Test port 2 coupler
A27
A28
A29
A30
5087-7241
5087-6241
4
Channel A first converter (mixer)
Channel R1 first converter (mixer)
Channel R2 first converter (mixer)
Channel B first converter (mixer)
A31
A32
A33
A34
E8364-60134
E8364-69134
4
Channel A receiver module
Channel R1 receiver module
Channel R2 receiver module
Channel B receiver module
A35 E8364-60135 1 Receiver motherboard
A41 Hard disk drive assembly. Refer to “Hard Disk Drive Assembly” on page 6-36.
➀
E8364-60139 1 LO reject filter board
