6-30 Service Guide E8361-90001
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8361A
Parts Included with Option 014 (with or w/o Option 080)
Reference
Designator
Part
Number
Qty Description
A9, A13
Not shown. See “Top Assemblies and Hardware, All Options
Including 080” on page 6-14. (Option 080)
W60 E8361-20023 6 RF cable: Front-panel jumper
W61 E8361-20021 1 RF cable: A23 SOMA 70 to port 1 SOURCE OUT
W62 E8361-20022 1 RF cable: A24 SOMA 70 to port 2 SOURCE OUT
W63 E8361-20011 1 RF cable: Port 1 CPLR THRU to A25 test port 1 coupler
W64 E8361-20012 1 RF cable: Port 2 CPLR THRU to A26 test port 2 coupler
W65 E8361-20015 1 RF cable: SOMA 70 to channel R1 SOURCE OUT
W66 E8361-20016 1 RF cable: SOMA 70 to channel R2 SOURCE OUT
W67
E8361-20018
1 RF cable: A25 test port 1 coupler to Port 1 CPLR ARM
W68 1 RF cable: A26 test port 2 coupler to Port 2 CPLR ARM
W69 E8361-20013 1 RF cable: A IN to A27 channel A mixer
W70 E8361-20019 1 RF cable: R1 IN to A28 channel R1 mixer
W71 E8361-20020 1 RF cable: R2 IN to A29 channel R2 mixer
W72 E8361-20014 1 RF cable: B IN to A30 channel B mixer
W91-94
Not shown. See “Top Cables, All Options Including 080” on
page 6-18. (Option 080)
W95 E8364-60017 1
Flexible cable: A35 receiver motherboard J502
to A13 frequency offset receiver assembly (Option 080)
To Next Page
