7-30 Service Guide E8361-90001
Repair and Replacement Procedures PNA Series Microwave Network Analyzers
Removing and Replacing the A16 Test Set Motherboard E8361A
Removing and Replacing the A16 Test Set Motherboard
Tools Required
T-10 TORX driver (set to 9 in-lb)
T-20 TORX driver (set to 21 in-lb)
5/16-inch open-end torque wrench (set to 10 in-lb)
ESD grounding wrist strap
Removal Procedure
Refer to Figure 7-13 for this procedure.
1. Disconnect the power cord.
2. Remove the outer covers. Refer to “Removing the Covers” on page 7-6. Position the
analyzer bottom side up and raise the receiver deck as shown. Refer to “Raising and
Removing the Receiver Deck” on page 7-8 if necessary.
3. Remove the A21 SOMA 50. Refer to “Removing and Replacing the A21 SOMA 50” on
page 7-40.
4. Remove the A41 hard disk drive and stationary board (shield). Refer to “Removing and
Replacing the A41 Hard Disk Drive” on page 7-56.
5. Disconnect the ribbon cables (item
) from the A16 test set motherboard:
A14 system motherboard ribbon cable
A17 LOMA 12 ribbon cable
A18 MA 24 ribbon cable
A20 LODA ribbon cable
A23 and A24 SOMA 70s ribbon cables
A35 receiver motherboard ribbon cable
Mixer bias board ribbon cable
6. Disconnect the wrapped-wire cables and flexible RF cables (item
) from the A16 test
set motherboard:
Front-panel LED board cable
A22 switch cable
A23 and A24 SOMA 70s flexible RF cables
7. Release the flexible RF cables from the cable clamp (item
). Release the receiver deck
by pulling the latch pin (item
), and move the entire receiver deck out of the way.
8. With a T-10 TORX driver, remove the following screws:
•Nine screws (item
) from the rear panel.
•Four screws (item ) from the A16 test set motherboard.
9. Slide the A16 test set motherboard toward the front of the instrument to release the
locking pins (item
), then lift the motherboard and remove it from the analyzer.
Replacement Procedure
1. Reverse the order of the removal procedure.
2. Perform the post-repair adjustments, verifications, and performance tests that pertain
to this removal procedure. Refer to Table 7-2 on page 7-66.
