6-10 Service Guide E8361-90001
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8361A
Front Panel Assembly, All Options
Reference
Designator
Part
Number
Qty Description
A1
E8356-60001 1 Keypad assembly
A2
a
a. When ordering a replacement A2 display assembly, you must also order item ➅.
E8356-60002 1 Display assembly
0950-3379 1
Inverter board (included in A2
b
)
b. Although included in the A2 display assembly, each of these parts is also available separately. If one
of these parts should have to be replaced, it is not necessary to replace the entire A2 display
assembly. For any other parts failures within the display, replace the entire A2 display assembly.
2090-0386 1
Display lamp for LCD (included in A2
b
)
1000-1161 1
Display glass (included in A2
b
)
A3
E8356-60209 1 Front panel interface board
RPG
E8356-40006 1 Front knob
➀
5041-9183 2 With handles—front handle side trim
5041-9174 2 Without handles—trim strip, filler
➁
c
c. For part numbers of complete rack mount kits and handle kits, refer to “Rack Mount Kits and
Handle Kits” on page 6-40.
5063-9205 2 Front handle
➂
E8361-80002 1 Front panel overlay, no options
E8361-80003 1 Front panel overlay, option 014 or option 014, 080
➃
E8356-00025 1 Trim strip, filler
➄
0515-1227 2
Machine screw, M3.0 x 6 FL-TX (to attach item
➃)
➅
E8361-80001
1Nameplate
➆
d
d. When ordering a replacement front frame assembly, you must also order item ➂.
E8364-60015 1 Front frame assembly
➇
0515-0375 4 Machine screw, M3.0 x 14 CW-PN-TX
➈
0515-0372 8 Machine screw, M3.0 x 8 CW-PN-TX
