3-2 Service Guide E8361-90001
Tests and Adjustments PNA Series Microwave Network Analyzers
Information in This Chapter E8361A
Information in This Chapter
This chapter contains procedures to help you check, verify, and adjust your PNA series
network analyzer.
• The checks verify the operation of the assemblies in your analyzer.
• The verification compares the operation of your analyzer to a gold standard.
• The adjustments allow you to tune your analyzer for maximum response.
NOTE A description of the performance tests in the Agilent N2721A software
package is included in this chapter. The Agilent N2721A software package
must be purchased separately.
Chapter Three at-a-Glance
Section Title Summary of Content Start Page
Before You Begin
Items to consider or procedures to perform before
testing is begun:
• Verify the Operating Environment
• Protect Against Electrostatic Discharge (ESD)
• Allow the Analyzer to Warm Up
• Review the Principles of Connector Care
Page 3-4
About System
Verification and
Performance Tests
Descriptions of:
• System Specifications
• Instrument Specifications
• System Verification Procedure
• Performance Tests
• Certificate of Calibration
Page 3-6
ANSI/NCSL
Z540–1–1994
Verification
The ANSI/NCSL Z540-1-1994 process of verifying your
analyzer.
Page 3-8
Non-ANSI/NCSL
Z540–1–1994
Verification
The non-ANSI/NCSL Z540-1-1994 process of verifying
your analyzer.
Page 3-9
