2-6 Service Guide E8361-90001
General Product Information PNA Series Microwave Network Analyzers
Required Service Test Equipment E8361A
Required Service Test Equipment
Microsoft® and Windows® are U.S. registered trademarks of Microsoft Corporation.
Equipment Critical Specifications
Recommended
Model or Part
Number
Alternate
Model or
Part
Number
Use
a
a. P = Performance tests, A = Adjustments, T = Troubleshooting, V = System verification
Test Instruments and Software
Frequency counter
Freq: 10 MHz to 24 GHz
Accuracy : ±0.5 ppm
53151A
Opt 001
None P, A,T
Spectrum analyzer
Min Freq: 1 MHz
Max Freq: > 4 GHz
Resolution BW: 300 Hz
8565E
856xE A,T
Power meter Accuracy: ±0.0068 dB
E4418B/19B
Opt G12 or H12
b
b. The accuracy of a standard E4418B or E4419B of ±0.02 dB is adequate for all tests except
“Dynamic Accuracy Test.” This test requires a power meter with Option G12 or H12 that has
been certified to a higher accuracy specification. If an Option G12 or H12 power meter is not
available, a test is provided on page 3-36 to verify the accuracy of a standard power meter.
E4418A/19A
c
c. If an accurate measurement of the dynamic accuracy specification is not required, the E4418A or
E4419A can be used.
P, A ,T
Power sensor
Freq: 10 MHz to 4.2 GHz
Range: –30 to +20 dBm
8482A
None
P, A ,T
Power sensor
Freq: 4.2 GHz to 50 GHz
Range: –30 to +20 dBm
8487A
None
P, A ,T
Power sensor
d
d. This sensor and adapter must be calibrated together by the Agilent factory. The data supplied is
only valid as long as the sensor and adapter remain connected.
Freq: 4.2 GHz to 67 GHz
Range: –30 to +20 dBm
V8486A None P, A, T
Adapter
d
(WR-15 to 1.85 mm)
Return Loss: ≥ 22 dB V281A None P, A, T
Dynamic accuracy
test set
None specified
Z5623A
Opt H01
None P
Digital voltmeter Resolution: 10 mV Any Any T
Printer N/A
Any printer with Microsoft®
Windows® 2000 driver
P
Test software
e
e. The recommended model or part number for all equipment listed with a “P” in the Use column is
required for proper operation of this test software.
N/A
N2721A
f
f. Available June 2003.
None
P
