Service Guide E8361-90001 2-7
PNA Series Microwave Network Analyzers General Product Information
E8361A Required Service Test Equipment
Equipment
a
Critical Specifications
Recommended
Model or Part
Number
Alternate
Model or
Part
Number
Use
b
Calibration and Verification Kits
1.85 mm calibration kit Freq: 10 MHz to 67 GHz 85058B 85058E P,T
1.85 mm verification kit Freq: 10 MHz to 67 GHz
85058V
c
None V
ECal module Freq: 10 MHz to 67 GHz N4694A None P,A, T
Cables
BNC cable (2 required) 50Ω, length ≥ 60 cm 8120-1839 None A
1.85 mm RF cable (Qty 2) 50Ω, length ≥ 60 cm N4697F Equivalent P,A,V
GPIB cable N/A 10833A/B/C/D None P,A
Adapters
WR-15 to 1.85 mm (m) Return Loss: ≥ 22 dB V281B None P,A,T
1.85 mm (f) to 1.85 mm (f) Return Loss: ≥ 22 dB
85058-60114
d,
e
None P,A,T
2.4 mm (f) to 2.4 mm (f) Return Loss: ≥ 26 dB 11900B 85056-60007 P,A,T
Adapter, 3.5 mm (m) to
2.4 mm (f)
Return Loss: ≥ 32 dB
11901D
E4413A
f
P, A , T
2.4 mm (f) to Type-N (f)
g
Return Loss: ≥ 28 dB 11903B None P,A,T
Adapter, SMA (m) to SMA
(f), right angle
Return Loss: ≥ 20 dB 1250-1249 Equivalent A
Attenuators
1.85 mm, 10-dB fixed
attenuator, (m,f)
Freq: 10 MHz to 67 GHz Anritsu 41V-10 None P
1.85 mm, 20-dB fixed
attenuator, (m,f)
Freq: 10 MHz to 67 GHz Anritsu 41V-20 None P
a. Unless specified otherwise, equipment listed is required for all analyzer models.
b. P = Performance tests, A = Adjustments, T = Troubleshooting, R = Repair, V = System verification
c. Available in May 2003.
d. Included in the 85058B/E calibration kits.
e. This adapter is included in the calibration kit 85058B, and is only required when using the ECal
module—model N4694A—is used to perform the calibration.
f. The E4413A 3.5 mm power sensor may be used instead of the 8487A power sensor and 11901D
adapter.
g. The 1.85 mm connector has the same ruggedness and is compatible with the 2.4 mm connectors.
1.85 mm and 2.4 mm adapters may be used interchangeably.
