2-8 Service Guide E8361-90001
General Product Information PNA Series Microwave Network Analyzers
Required Service Test Equipment E8361A
Equipment
a
Critical Specifications
Recommended
Model or Part
Number
Alternate
Model
Number
Use
b
Tools
Extender board N/A E8356-60021 None T
T-8 TORX driver 5 in-lb setting N/A N/A R
T-10 TORX driver 4, 7, and 9 in-lb settings N/A N/A T,R
T-20 TORX driver 21 in-lb setting N/A N/A T,R
5/16-inch, open-end torque
wrench
10, and 21 in-lb settings
(for semi-rigid cables)
N/A N/A T,R
1-inch, open-end torque
wrench
72 in-lb setting (for Port 1
and Port 2 connectors)
N/A N/A R
1/4-inch and 5/16-inch
open-end wrench
Thin profile 8710-0510 N/A A,R
Static Safety Parts
Adjustable antistatic wrist
strap
N/A 9300-1367 None P,A,T
Antistatic wrist strap
grounding cord (5 foot)
N/A 9300-0980 None P,A,T
Static control table mat and
earth ground wire
N/A 9300-0797 None P,A,T
Floppy disks 3.5 inch Any None A
a. Unless specified otherwise, equipment listed is required for all analyzer models.
b. P = Performance tests, A = Adjustments, T = Troubleshooting, R = Repair, V = System verification
