D-6 Service Guide E8361-90001
Operating System Recovery PNA Series Microwave Network Analyzers
System Recovery Procedure E8361A
If the Operating System Does Not Boot From the Floppy Disk Drive
You may have to change the network analyzer Bios settings to have it scan the floppy disk
drive before booting from the hard disk drive. Due to Bios revisions, the exact procedure
may vary slightly from the following:
1. Attach a keyboard to the network analyzer and restart the network analyzer.
2. When the Agilent logo appears, press function key
F2, on the keyboard, several times.
The
Bios menu will appear after several seconds.
3. Using the keyboard arrows, select Boot. Use the keyboard to edit the file to select
booting from the floppy disk drive before attempting to boot from the hard disk drive.
NOTE Once the restoration process is complete and the analyzer is functioning
properly, remove the floppy disk and use this same procedure to change back
to booting from the hard disk drive. If you do not do this, an error will result
each time the analyzer is powered up with a floppy disk installed.
4. Select
Save, and then Exit.
5. Now that the Bios has been changed to allow the system to detect the DOS boot disk in
the floppy disk drive, continue with the procedure at step 5 of “If the Operating System
Does Not Boot From the Hard Disk Drive” on page D-5.
