6-28 Service Guide E8361-90001
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8361A
Bottom Hardware, No Options
Reference
Designator
Part
Number
Qty Description
➀
E8361-00001 2 SOMA 70 bracket
➁
E8364-20115 1 mixer bracket
➂
E8361-60001 1 mixer bias board
➃
0515-0430 9
Machine screw M3.0 x 6 CW-PN-TX
(SOMA 70 bracket-3 ea; front-panel LED board-3)
➄
0515-0372 2
Machine screw M3.0 x 8 CW-PN-TX
(A35-2)
➅
0515-0374 17
Machine screw M3.0 x 10 CW-PN-TX
(A17-3; A18-4; A20-2: A22-4; mixer bracket-4)
➆
0515-0664 14
Machine screw M3.0 x 12 CW-PN-TX
(A19-2; A16-4; LO reject filter board-8)
➇
0515-0666 37
Machine screw M3.0 x 18 CW-PN-TX
(A35 casting-13; A20-4; A27–A30-3 ea;
A23/A24-4 ea)
➈
0515-1349 16
Machine screw M3.0 x 30 CW-PN-TX
(A31–A34-3 ea; A21-4)
➉
08720-60182 1
Front-panel LED board
5022-1087 2 Test port coupler nut
11
