6-38 Service Guide E8361-90001
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8361A
Miscellaneous Part Numbers
Description
Model or Part
Number
Service Tools
Extender board, synthesizer/reference E8356-60021
T-8 TORX driver (set to 5 in-lb) N/A
T-10 TORX driver (set to 9 in-lb) N/A
T-20 TORX driver (set to 21 in-lb) N/A
5/16-in, open-end torque wrench (set to 10 in-lb) N/A
1/4-in to 5/16-in open-ended wrench N/A
Documentation
Installation and Quick Start Guide (for all PNA series analyzers) E8356-90001
Service Guide (this manual) E8361-90001
CD-ROM (Includes the following:) E8356-10001
Installation and Quick Start Guide in PDF format
Service Guide in PDF format
Embedded Help in PDF format
Embedded Help program to run on a PC
Protective Caps for Connectors
Protective cap for GPIB connector
1252-5007
Protective cap for Test Set I/O connector 1252-4690
Protective cap for Aux I/O connector 1252-4691
Protective cap for Handler I/O connector 1253-5320
Protective cap for Display (VGA) connector 1252-4696
Protective cap for Serial (RS-232) connector 1252-4697
Protective cap for Parallel (1284-C) connector 1252-4690
Protective cap for Test port (Port 1, Port 2) connector 1401-0247
GPIB Cables/GPIB Adapter
GPIB cable, 0.5 meter (1.6 feet) 10833D
GPIB cable, 1 meter (3.3 feet) 10833A
GPIB cable, 2 meter (6.6 feet) 10833B
GPIB cable, 4 meter (13.2 feet) 10833C
GPIB cable to GPIB cable adapter 10834A
