Agilent Technologies PNA Series User Manual

6-22 Service Guide E8361-90001
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8361A
Bottom RF Cables, No Options
Reference
Designator
Part
Number
Qty Description
W1
E8364-20036 1 A21 SOMA 50 to A12 source 20 assembly
W2 E8361-20002 1 A21 SOMA 50 to A22 switch
W3
E8361-20003 1 A22 switch to A23 SOMA 70
W4
E8361-20004 1 A22 switch to A24 SOMA 70
W5 E8361-20005 1 A23 SOMA 70 to A25 test port 1 coupler
W6 E8361-20006 1 A24 SOMA 70 to A26 test port 2 coupler
W7
E8361-20009 1 A23 SOMA 70 to A28 channel R1 mixer
W8
E8361-20010 1 A24 SOMA 70 to A29 channel R2 mixer
W9 E8361-20007 1 A25 test port 1 coupler to A27 channel A mixer
W10 E8361-20008 1 A26 test port 2 coupler to A30 channel B mixer
W11 E8364-20171 1 A20 LODA to A27 channel A mixer
W12 E8364-20172 1 A20 LODA to A28 channel R1 mixer
W13 E8364-20173 1 A20 LODA to A29 channel R2 mixer
W14 E8364-20146 1 A20 LODA to W15 (to A30 channel B mixer)
W15 E8364-20032 1 A30 channel B mixer to W14 (to A20 LODA)
W16 E8364-20169 1 A19 splitter to A20 LODA
W17 E8364-20170 1 A19 splitter to A20 LODA
W18 E8364-20029 1 A18 MA 24 to A19 splitter
W19 E8364-20145 1 A18 MA 24 to A17 LOMA 12
W20 E8364-20057 1
A17 LOMA 12 J2
to A8 fractional-N synthesizer board J106
W21 E8364-20027 1
A17 LOMA 12 J3
to A8 fractional-N synthesizer board J101
