6-12 Service Guide E8361-90001
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8361A
Top Assemblies and Hardware, All Options Except 080
Reference
Designator
Part
Number
a
a. Part numbers in italic typeface are for rebuilt exchange assemblies. Refer to “Rebuilt-Exchange
Assemblies” on page 6-5.
Qty Description
A4 0950-4219 1 Power supply assembly
A6 E8356-60006 1 Signal processing ADC module (SPAM) board
A8 E8364-60099 1 Fractional-N synthesizer board
A10 E8364-60136 1 Frequency reference board
A11 E8364-60137 1 Phase lock board
A12
E8361-60002
E8361-69002
1 Source 20 assembly
A14 E8364-60100 1 System motherboard
A15 E8801-60055 1 500 MHz CPU board
A40 Floppy disk drive
Refer to “Internal Hardware and Parts, All Options” on
page 6-32.
B1 Fans
➀
5022-6134 1 Cable hold down
➁
5022-6135 1 Cable hold down
➂
E8356-40001 1 Air flow plenum
➃
E8356-60202 1 USB hub board
To Next Page
