6-24 Service Guide E8361-90001
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8361A
Bottom Flexible Cables, No Options
Reference
Designator
Part
Number
Qty Description
W23 E8364-60019 1
A27 channel A mixer
to LO reject filter board
W24 E8364-60020 1
A28 channel R1 mixer
to LO reject filter board
W25 E8364-60021 1
A29 channel R2 mixer
to LO reject filter board
W26 E8364-60022 1
A30 channel B mixer
to LO reject filter board
W27
8120-5014
1
LO reject filter board to A31 receiver A
W28
1
LO reject filter board to A32 receiver R1
W29
1
LO reject filter board to A33 receiver R2
W30
1
LO reject filter board to A34 receiver B
W31 E8364-60126 1
A31 receiver A J400
to A6 SPAM board J3
W32 E8364-60127 1
A32 receiver R1 J400
to A6 SPAM board J4
W33 E8364-60128 1
A33 receiver R2 J400
to A6 SPAM board J5
W34 E8364-60129 1
A34 receiver B J400
to A6 SPAM board J6
W35 E8364-60124 1
A35 receiver motherboard J2
to A10 frequency reference board J4
W36 E8364-60125 1
A35 receiver motherboard J50
to A11 phase lock board J6
W37 E8364-60161 1
LO reject filter board P2
to A16 test set motherboard J15
W38 E8361-60124 1
A16 test set motherboard
to A23 SOMA 70
W39 E8361-60123 1
A16 test set motherboard
to A24 SOMA 70
W40 E8364-60123 1
A16 test set motherboard
to A21 SOMA 50
