Agilent Technologies PNA Series User Manual

6-26 Service Guide E8361-90001
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings E8361A
Bottom Ribbon Cables and Wrapped-Wire, No Options
Reference
Designator
Type
a
a. nW = n wires in a wrapped cable; nR = n wires in a ribbon (flat) cable
Part
Number
Description
➀
50R 8121-0817
A41 hard disk drive assembly
to A15 CPU board
➁
26R 8121-0818
A16 test set motherboard
A21 SOMA 50
➂
40R 8121-0834
A16 test set motherboard
to rear-panel connector
➃
60R 8121-0965
A16 test set motherboard
to A35 receiver motherboard and LO reject filter board
➄
24R 8121-0815
A16 test set motherboard
to A18 MA 24
➅
16R 8121-0816
A16 test set motherboard
to A20 LODA
➆
20R 8121-0846
A16 test set motherboard
A17 LOMA 12
➇
2W 8121-0990
A16 test set motherboard
to A22 switch
➈
20R 8121-1001
A16 test set motherboard to A23 SOMA 70
A16 test set motherboard to A24 SOMA 70
➉
14R 8121-0814
A16 test set motherboard
to mixer bias board
4W 8121-0802
A16 test set motherboard
to front-panel LED board
100R 8121-0118
A14 system motherboard
to A16 test set motherboard
11
12
