Service Guide E8361-90001 3-41
PNA Series Microwave Network Analyzers Tests and Adjustments
E8361A Adjustments
Adjustments
These adjustments are firmware-driven tests that are used to fine-tune your analyzer for
optimum response. The tests are as follows:
• “Source Calibration Adjustment” on page 3-42
• “Receiver Calibration Adjustment” on page 3-44
• “LO Power Adjustment” on page 3-47
• “LO Offset Adjustment” on page 3-48
• “10 MHz Frequency Reference Adjustment” on page 3-50
• “3.8 GHz PMYO Frequency Adjustment” on page 3-51
