Agilent Technologies PNA Series User Manual

3-40 Service Guide E8361-90001
Tests and Adjustments PNA Series Microwave Network Analyzers
Performance Tests (Agilent N2721A Software Package) E8361A
TEST RECORD FOR POWER METER ACCURACY TEST
Power Meter Tested: Model No.: Serial No:
Date: Tested by:
Test Equipment Used
Range Calibrator: Model No.: 11683A
Serial No.:
Digital Voltmeter: Model No.: Serial No.:
Test Results
Range
Calibrator
Setting
Channel A Channel B
DVM Reading
(Vdc)
Power Meter
Reading (dBm)
DVM Reading
(Vdc)
Power Meter
Reading (dBm)
1 mW A = 0.000 ±0.001 A = 0.000 ±0.001
300 µWB =C =B =C =
100 µWD =E =D =E =
Pass/Fail Calculations
300 µW
R = B/A = R = B/A =
S = 10
(C/10)
= S = 10
(C/10)
=
% ERROR = ((R-S)/R) × 100 = % % ERROR = ((R-S)/R) × 100 = %
Limits: ±0.13% Limits: ±0.13%
Pass Fail Pass Fail
100 µW
T = D/A = T = D/A =
U = 10
(E/10)
= U = 10
(E/10)
=
% ERROR = ((T-U)/T) × 100 = % % ERROR = ((T-U)/T) × 100 = %
Limits: ±0.10% Limits: ±0.10%
Pass Fail Pass Fail
