7-4 Service Guide E8361-90001
Repair and Replacement Procedures PNA Series Microwave Network Analyzers
Removal and Replacement Procedures E8361A
Removal and Replacement Procedures
Table 7-1 List of Procedures
Reference
Designator
Assembly Type Location
N/A Covers, outer and inner Page 7-6
N/A Receiver deck Page 7-8
N/A L.O. reject filter board (part of A31, A32, A33, A34 procedure) Page 7-50
N/A Midweb and fans Page 7-62
N/A Front panel assembly Page 7-10
N/A Mixer bias board (part of A27, A28, A29, A30 procedure) Page 7-48
N/A USB hub Page 7-65
A1 Keypad assembly
Page 7-12A2 Display assembly
A3 Front panel interface board
A4 Power supply assembly Page 7-16
A6 SPAM board
Page 7-18
A8 Fractional-N synthesizer board
A9 Fractional-N synthesizer board (Option 080)
A10 Frequency reference board
A11 Phase lock board Page 7-20
A12 Source 20 Page 7-22
A13 Frequency offset receiver board Page 7-24
A14 System motherboard Page 7-26
A15 CPU board Page 7-28
A16 Test set motherboard Page 7-30
A17 LOMA 12 Page 7-32
A18 MA 24 Page 7-34
A19 Splitter Page 7-36
