5 Using the Data Logger Functions
118 Agilent U1602B/U1604B User’s and Service Guide
Data Logger Function
The data logger plots the graph from left to right until the screen reaches
the right edge of the screen. The data logging function automatically
compresses the screen to half with the time base changes as follows:
• 150 seconds
• 300 seconds
• 10 minutes
• 20 minutes
• 50 minutes
• 100 minutes
• 200 minutes
• 10 hours
• 20 hours
• 30 hours
• 60 hours
• 120 hours
• 10 days
• 20 days
The time base increments changes by every 10 divisions from a minimum
of 15 s/div (150 seconds) to maximum of 2 days/div for data logging. To
utilize this function, do the following:
1 Press button to access data logger mode.
2 Press F1 to select the following multimeter functions for data logging:
• Voltmeter (displayed as “Volt”)
• Ohmmeter (displayed as “Ohm”)
• Auxiliary meter (displayed as “Aux”)
3 After selecting the multimeter function, press F2 to select the
sub- function of each multimeter function, listed as below:
To Next Page
