Agilent Technologies U1602B User Manual

Performance Tests 7
144 Agilent U1602B/U1604B User’s and Service Guide
Table 7 - 5 DC Volts Verification Test
Figure 7-2 Test connections from calibrator to instrument
Calibrator Voltage Function Range Min Limit Max Limit
600 mV DC Volts 600 mV 597.7 mV 602.3 mV
6 V 6 V 5.977 V 6.023 V
30 V 60 V 29.86 V 30.14 V
60 V 60 V 59.77 V 60.23 V
600 V 600 V 597.7 V 602.3 V
