25
Agilent U1602B/U1604B Handheld Digital Oscilloscope
User’s and Service Guide
Agilent Technologies
3
Using the Scope Functions
Vertical Controls 26
Horizontal Controls 36
Trigger Controls 43
Waveform Controls 52
Display Controls 55
Automatic Measurement 58
Cursor Measurement Controls 67
Math Functions Control 74
Save and Recall Controls 79
Autoscale and Run/Stop Controls 92
Utility Controls 94
Low Battery Mode 96
Mute Function 97
This section guides you through the operation steps in setting up the
vertical system control of the instrument. It is highly recommended that
you read through this chapter to get familiar with the basic operation
setup before performing measurements with the instrument.
• For option selections in all function menus, press the respective softkey to select and
set the option with a tick (√ ) is shown.
• For any adjustment using rotary switch, the menu displays to indicate the rotary
switch is required for the adjustment.
