7Performance Tests
Agilent U1602B/U1604B User’s and Service Guide 153
The self- calibration error code carry 15 bits (0 to 14 as stated in the bit
number in Table 6- 1). The bit number is expressed in hexadecimal with
pass as “0” and fail as “1”. See below for examples:
1 In all pass status, the instrument displays “OK” instead of hexadecimal
code (0x0000)
2 In all fail status, the instrument displays 0x7fff.
0000 0111 1111 1111 1111
0x 7 f f f (Hexadecimal code)
3 If multi- error occurred in TE3, TE4, OE2 and OE3, the hexadecimal
code “0x600C” will be displayed as self- calibration result.
0000 0110 0000 0000 1100
0x 6 0 0 C (Hexadecimal code)
bit [15]
bit [0]
