Vertical sensitivity 5 mV/div to 100 V/div (1:1 passive probe)
50 mV/div to 1 kV/div (10:1 passive probe)
500mV/div to 10 kV/div (100:1 passive probe)
Maximum input CAT III 300 Vrms (up to 400 Hz) from terminal to ground
Offset/Dynamic range ± 5 div
Input impedance 1 MW || < 20 pF
Coupling AC, DC, GND
Probes U1560-60001 1:1 passive probe
U1561-60001 10:1 passive probe
U1562-60001 100:1 passive probe
Probe attenuation factors 1x, 10x, 100x
Probe compensation output 3 Vp-p, ~ 1 kHz
Maximum probe input 1x CAT III 300 VAC
10x, 100x CAT III 600 VAC
Noise peak-to-peak 3% of full scale or 5 mV, whichever is greater
DC vertical offset accuracy ±0.1 div ±2 mV ±0.5% offset value
Single cursor accuracy 4% full scale
Dual cursor accuracy 4% full scale
Horizontal System
Range U1602B: 50 ns to 50 s/div
U1604B: 10 ns to 50 s/div
Resolution U1602B: 2 ns
U1604B: 400 ps
Reference position Left, center, right
Delay range (pre-trigger) 15 divisions
Delay range (post-trigger) 1000 divisions
Analog Dt accuracy ± 3% reading ± 0.4% screen
Modes Main, XY, Roll
RMS Jitter 5% of horizontal scale or 5 ns whichever is higher
