E16 Door Phone Administrator Guide
9
4 Access the Device
E16 series door phones' system settings can be either accessed on the device directly or
on the device web interface.
4.1 Access the Device Setting on the device
If you want to access the device setting in order to configure and adjust the parameters,
you can do it directly on the device. To access the device setting, you can long press on
the initial screen for approximately five seconds, then enter the default PIN code
admin and press Confirm.
4.2 Access the Device Setting on the Web Interface
You can also use the Akuvox IP scanner tool to search the device's IP address on the same
LAN. Then enter the device IP address on the web browser in order to login to the device
web interface where you can configure and adjust parameters etc. Then use the IP
address to login into the web browser by user name and password admin and admin.

Akuvox E16C Specifications

General

Color	Yes
Speakerphone	No
Connectivity technology	Wired
Number of displays supported	-
Display diagonal	5 \
Display resolution	1280 x 720 pixels
Display technology	IPS
Proper use	Indoor
Product color	Black
Housing material	Plastic
International Protection (IP) code	IP65
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Megapixel	2 MP
Indoor unit power type	DC
Operating temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Quantity per pack	1 pc(s)
Operating system installed	Linux

Weight and Dimensions

Depth	27.5 mm
Width	88 mm
Height	192 mm
