E16 Door Phone Administrator Guide
13
5.3 LED Setting
5.3.1 Configure Card Reader LED Setting
You can enable or disable the LED lighting on the card reader area as needed on the web
interface. Meanwhile, if you do not want the card reader LED light to stay on, you can also
set the timing for the exact time span during which the LED light can be disabled to reduce
the electrical power consumption. To configure the configuration on the web Device >
Light > LED Of Swiping Card Area interface.
Parameter Set-up:
• Enabled: tick the check box you want to enable the card reader LED lighting and vice
versa.
• Start Time- End Time (H): enter the time span for the LED lighting to be valid, eg. if
the time span is from 18-22, it means the LED light will stay on during the time span
from 6:00 pm to 10:00 pm during one day (24 hours).
5.3.2 Configure LED White Light Setting
LED White light is used to reinforce the lighting for facial recognition as well as for QR
code access in the dark environment. To configure the function, go to Device >
Light > White Light interface.
Parameter Set-up:

Akuvox E16C Specifications

General

Color	Yes
Speakerphone	No
Connectivity technology	Wired
Number of displays supported	-
Display diagonal	5 \
Display resolution	1280 x 720 pixels
Display technology	IPS
Proper use	Indoor
Product color	Black
Housing material	Plastic
International Protection (IP) code	IP65
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Megapixel	2 MP
Indoor unit power type	DC
Operating temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Quantity per pack	1 pc(s)
Operating system installed	Linux

Weight and Dimensions

Depth	27.5 mm
Width	88 mm
Height	192 mm
