Akuvox R20A Series User Manual

Single Tenant Door Phone
AKUVOX SMART INTERCOM www.akuvox.com
7
5.Access the Device
R20A/R20B/R26C/R26P/E11R/E21V/E21A/E12W series system setting can
be accessed on the device web interface.
5.1. Obtain Device IP Address
Check the Device IP address by holding the push button for 5s. Or searching
the device IP by the IP scanner in the same LAN network. Just click Scan tab
in IP scanner to check the device IP.
Note:
 For R20B, just holding the first push button for 5s to get the IP
address.

Akuvox R20A Series Specifications

General

Installation	Wall-mounted
Protection level	IP65
RS485	Yes
Camera	2MP
Audio	Built-in microphone and speaker
Network	10/100Mbps Ethernet
Protocols	SIP, RTSP
Power	PoE or 12V DC
