Akuvox R20A Series User Manual

Single Tenant Door Phone
AKUVOX SMART INTERCOM www.akuvox.com
83
 Common AES Key: set up AES code for the intercom to decipher general
Auto Provisioning configuration file.
 AES Key (MAC): set up AES code for the intercom to decipher the
MAC-based auto provisioning configuration file.
Note:
 AES is one type of encryption, it should be configured only when the
config file is encrypted with AES, otherwise leave the field blank.
Note:
Server Address format:
 TFTP: tftp://192.168.0.19/
 FTP: ftp://192.168.0.19/ (allows anonymous login)
 ftp://username:password@192.168.0.19/(requires a user name
and password)
 HTTP: http://192.168.0.19/ (use the default port 80)
 http://192.168.0.19:8080/ (use other ports, such as 8080)
 HTTPS: https://192.168.0.19/ (use the default port 443)
Tip:
 Akuvox do not provide user specified server.
 Please prepare TFTP/FTP/HTTP/HTTPS server by yourself.

Akuvox R20A Series Specifications

General

Installation	Wall-mounted
Protection level	IP65
RS485	Yes
Camera	2MP
Audio	Built-in microphone and speaker
Network	10/100Mbps Ethernet
Protocols	SIP, RTSP
Power	PoE or 12V DC
