Keys that are preprogrammed at attendant set installation are shown grayed (dark
background).
Note:
Key 11 used for preprogrammed HOLD feature in certain countries.
1.3.1 Preprogrammed keys
Key Function Status of the corresponding
LCD blocks
1 Call presentation: although this key may
be modified by the system manager, it
is advisable to leave the prepro-
grammed function for call display.
Note 1:
The different types of calls are described be-
low this table.
: incoming call(s).
Note 2:
The display indicates the number of
waiting calls.
13
Common hold (may be modified by the
manager). Used to put a call on com-
mon hold (the call can be retrieved from
hold by any attendant in the attendant
group).
Off: no call on hold.
: call(s) on hold.
ON/OFF
14
Used to switch the set on/off (cannot be
modified).
: set ON (day status, set
connected/active), the display
shows waiting calls. With the set
OFF, the key has no LCD blocks
and the display shows Night.
SERVICE
16
Service key (cannot be modified): used
to access special features (chained
withdrawal, charge unit counter, for-
warding to another attendant, etc.)
Off: not activated
: switchover to SERVICE
mode from the idle position.
: switchover to SERVICE
mode from a call.
AUTO
18
Used to enable/disable automatic con-
nection.
Off: manual connection.
: automatic connection of
incoming calls.
Chapter
1
#$ % !
1-4
