1 Introduction
This User Manual details the operation of the Alcolizer LE5 alcohol breath testing instrument
and AlcoCONNECT software for managing and analysing breath test results.
2 Description of LE5
2.1 Equipment Overview
The LE5 Equipment List includes the following items:
 LE5 Handheld instrument Li-ION powered
 USB cable
 Battery Charger, vehicle 12/24VDC
 Battery Charger, mains
 Silicon protective cover and wrist strap
 Carry bag or protective hard case (optional)
 Bluetooth printer (optional).
2.2 Instrument Overview
The LE5 is a handheld instrument consisting of a hard-plastic outer case, silicon cover, wrist strap
and the following user displays, buttons and adaptor sockets (refer Figure 1):
a. Test Key
b. LCD Colour Graphics Display
c. Mouthpiece Locator and Sample Inlet Spigot
d. Up and Down Buttons
e. USB Port
Note
This User manual is applicable to the Alcolizer LE5 alcohol tester certified to AS3547:2019.
