REF: LE5 Alcohol Tester User Manual V16.docx Page 63 © Alcolizer Technology
Uncontrolled when printed
Figure 111 - Recalibration Due Now Message
18.2 Replacing Sample Module
Rather than returning the instrument to Alcolizer for calibration, the sample module can be removed
and sent in. This saves money and if the owner details are known and maintained with Alcolizer,
arrangements can be made to forward a replacement sample module prior to the calibration being
overdue.
Remove and replace the sample module as follows (Refer Figure 112):
Undo the single screw on the back of the main module
Slide off the out-of-cal sample module
Slide on the new sample module
Do up the single screw on the back of the main module.
Figure 112 - Replacing a Sample Module
Following the replacement of the sample module, send the out-of-calibration module back to
Alcolizer.
The instrument can be returned to Alcolizer Technology for calibration should the owner prefer
prior to the number of days warning message period expiring. To arrange calibration, contact
Caution
It is recommended that calibration of the instrument is performed before the warning message
period expires. This will ensure uninterrupted testing can continue.
Caution
Do not over tighten the sample module securing screw as this will damage the threaded portion.
Tighten only enough to prevent the sample module from sliding away from the main module.
