8.4 Auto Print
The Auto Print functions allow the automatic printing of results via a Bluetooth connection to a
paired printer.
There are two Auto Print modes and each of these have three options. These are Auto Print
Standard and Auto Print Passive. Both have the following options:
Positive - Prints positive results after tests are completed
All - Prints positive and zero results after tests are completed
None - Regardless of results: nothing is printed
8.4.1 Auto Print Standard
Auto Print Standard applies only to Mouthpiece (Active) testing. Depending on the Auto Print
Standard option selected, the following information will be printed following tests:
Positive - If alcohol is detected: a complete report including time, location (lat/long
if GSP enabled), result etc will be printer.
All - Regardless of results: a complete report including time, location (lat/long if
GPS enabled), result etc will be printed.
None - Regardless of results: nothing is transmitted
To set the LE5 to Auto Print Standard, scroll down until Auto Print Standard is selected. Positive
is the default option. To select All or None, press the test key until the desired option is
highlighted (Refer Figure 84).
Figure 84 - Auto Print Standard with the Three Options
8.4.2 Auto Print Passive
Auto Print Passive applies only to Passive Testing. Depending on the Auto Print Passive option
selected, the information may be printed following the various tests except None. The result will
be either false if no alcohol is detected or true if alcohol is detected per the following
explanations:
Positive - If alcohol is detected: A short report including time,
instrument information, etc will be printed.
Note
To ensure the correct operation of the Auto Print function, Auto Send Standard and Auto Send
Passive must be sent to None.
