Rockwell Automation Publication 1769-UM011H-EN-P - April 2012 11
Chapter 1
1769 CompactLogix Controllers Overview
This chapter introduces the 1769 CompactLogix controllers. These controllers
offer state-of-the-art control, communication, and I/O elements in a distributed
control package.
About the 1769
CompactLogix Controller
The 1769 CompactLogix controller offers state-of-the-art control,
communication, and I/O elements in a distributed control package.
Figure 1 - CompactLogix Controller and 1769 I/O Modules
CompactLogix Controller
1769 I/O Modules Connected
to the CompactLogix
Controller
