90 Rockwell Automation Publication 1769-UM011H-EN-P - April 2012
Chapter 6 Place, Configure, and Monitor I/O
Configure Distributed I/O
on a DeviceNet Network
To communicate with the I/O modules over a DeviceNet network, add the
DeviceNet bridge to the I/O Configuration folder of the controller. RSNetWorx
for DeviceNet software is used to define the scanlist within the DeviceNet
scanner to communicate data between the devices and the controller through the
scanner.
Figure 14 - DeviceNet Distributed I/O Configuration
…you build the I/O configuration in this order
For a typical distributed I/O network…
Device
Device
Single Network
ScannerController
Linking
Device
Controller
Linking
Device
Several Smaller Distributed Networks (subnets)
Add the local scanner module.
Scanner
DeviceDevice
Device
Device
DeviceDevice
Device
DeviceDeviceDevice
To Next Page
