Chapter 2 Install the 1769-L3x Controllers
Verify Compatibility
Before You Begin
Consider the following when planning your CompactLogix system:
• The CompactLogix controller is always the leftmost module in the system.
• The controller must be within four modules of the system power supply.
Some I/O modules may be up to eight modules away from the power
supply. See the documentation for your 1769 I/O modules for details.
• The 1769-L32E controller supports as many as 16 I/O modules and the
1769-L35E controller supports as many as 30 I/O modules. Both
controllers can use a maximum of 3 I/O banks with 2 expansion cables.
• The 1769-L32C controller supports as many as 16 I/O modules in a
maximum of 3 I/O banks with 2 expansion cables. The 1769-L35CR
controller supports as many as 30 I/O modules in a maximum of 3 I/O
banks with 2 expansion cables.
• The 1769-L31 controller supports as many as 16 I/O modules in a
maximum of 3 I/O banks with 2 expansion cables.
• Each I/O bank requires its own power supply.
• Only one controller can be used in a CompactLogix system.
• A 1769-ECR right end cap or 1769-ECL left end cap is required to
terminate the end of the communication bus.
WARNING:
• This equipment must be installed in an enclosure providing at least IP54
protection when applied in Zone 2 environments.
• This equipment shall be used within its specified ratings defined by
Allen-Bradley.
• Provisions shall be made to prevent the rated voltage from being exceeded by
transient disturbances of more than 40% when applied in Zone 2
environments.
• Secure any external connections that mate to this equipment by using screws,
sliding latches, threaded connectors, or other means provided with this
product.
• Do not disconnect equipment unless power has been removed or the area is
known to be nonhazardous.
ATTENTION: This equipment is not resistant to sunlight or other sources of
UV radiation.
IMPORTANT
The series B controllers are compatible only with the following:
• Controller firmware revision 20 and later
• RSLogix 5000 software version 20 and later.
Attempting to use controllers with incompatible software and firmware
revisions may result in the following:
• An inability to connect to the series B controller in RSLogix 5000 software
• Unsuccessful firmware upgrades in ControlFLASH™ or AutoFlash utilities
