106 Publication IASIMP-QS001C-EN-P - October 2009
Chapter 10 Create a Project Using RSLogix 5000 Programming Software
Add Ladder Logic to Test the Local 1769 Compact I/O Modules
All controllers
1. Expand the Tasks folders and
double-click MainRoutine.
A blank MainRoutine opens.
2. From the Element Toolbar, drag and drop an Examine On and an
Output Energize element onto the rung.
