Allen-Bradley CompactLogix Series User Manual

143Publication IASIMP-QS001C-EN-P - October 2009 143
Chapter 12
Create a PowerFlex 70 Application
In this chapter, you configure a PowerFlex 70 drive and add the drive to the RSLogix 5000
project created in Chapter 10
. You also download the project to the controller so you can test
communication with the drive.
Before You Begin
• Prepare the PowerFlex 70 drive and network adapter, see Chapter 4
• Create a project using RSLogix 5000 programming software, see Chapter 10
What You Need
• For an EtherNet/IP network, no additional software is needed
• For a ControlNet network, RSNetWorx for ControlNet software
• For a DeviceNet network, RSNetWorx for DeviceNet software

Allen-Bradley CompactLogix Series Specifications

General

Communication Ports	EtherNet/IP
Programming Software	Studio 5000 Logix Designer
Power Supply	24V DC
Series	CompactLogix
Programming Languages	Ladder Diagram (LD), Structured Text (ST), Function Block Diagram (FBD), Sequential Function Chart (SFC)
Operating Temperature	0°C to 60°C (32°F to 140°F)
Mounting	DIN rail
Processor Type	Various (depends on model)
