Publication IASIMP-QS001C-EN-P - October 2009 75
Prepare the PanelView Plus Terminal Chapter 6
Make Network Connections
Required for all controllers
1769-L32C or 1769-L35CR controllers
Connect an Ethernet cable.
Connect the other end of the cable to an
Ethernet switch.
Connect a ControlNet cable to port A.
Connect the tap to the ControlNet network.
